560A Single-Spring Water Pump Mechanical Seal Replace Aesseal replace MTU FP/T3S

Name: 560A SingleSpring Water Pump Mechanical Seal Replace Aesseal replace MTU FPT3S
Brand: YUE MI
Price: 1 USD

China 560A Single-Spring Water Pump Mechanical Seal Replace Aesseal replace MTU FP/T3S wholesale

Brand Name : YUE MI

Model Number : 560A

Certification : ISO SGS

Place of Origin : Guangzhou, China

MOQ : 15/PCS

Price : consult

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000/Set/Month

Delivery Time : 5-8 word days

Packaging Details : Details Carton

Spring Material : Stainless Steel

Transport Package : YUEMI Standard or Customised

Secondary Sealing : SIC CAR FKM

Service : OEM&ODM

Seal : Submersible Pump Seal

Spring Other Parts : SUS304 / SUS316

Stationary Ring : Ceramic/Sic/TC

Performance : Corrosion

Type : 560A

Contact Now

560A series mechanical seals can be used in pipeline circulating pumps for water supply, district heating system, industrial wastewater treatment, boiler feed water, etc. They are suitable for sealing of oil, water, salt, non-crystallizing solvents and other weakly corrosive fluids, and are characterized by the structure of internal mounting, single-end face, large spring, and rubber bellows structure.

Pressure	≤0.8 MPa
Temperature	-20~150 ºC
Speeds	≤10 m/sec

Rotary ring	carbon, resin-impregnated B tungsten carbide, cobalt-bound U1 tungsten carbide, nickel-bound U2 silicon carbide without free silicon Q1 silicon carbide with free silicon Q2
Stationary ring	tungsten carbide, cobalt-bound U1 tungsten carbide, nickel-bound U2 silicon carbide without free silicon Q1 silicon carbide with free silicon Q2 Alumina V
Auxiliary Seal	nitrile synthetic rubber P EP synthetic rubber E fluorocarbon synthetic rubber V
Spring or other metal parts	CrNi steel F CrNiMo steel G
Materials according to operating condition

560A Dimensions(mm)
d	D3	D1	L2	L1
8	18.2	21	7	12.2
9	18.2	24	7	16.2
10	20.6	24	7	16.2
11	20.6	24	7	16.2
12	21.8	26	7	17.2
13	21.8	26	7	17.2
14	26.4	28	7	18.2
15	26.4	28	7	18.2
16	26.4	32	8	19.2
17	29.5	32	8	19.2
18	29.5	35	8	19.2
19	29.5	35	8	19.2
20	31.6	38	8	20.2
22	33.6	40	8	20.2
25	39.6	44	9	20.2
28	45	46	9	21.2
30	46.6	50	9	22.2
32	46.6	54	9	24.2
35	50.8	58	10	26.2
38	54.3	60	10	27.2
40	57.3	64	10	28.2
45	61.3	66	10	30.2
50	67.8	72	10	32.2

560A Single-Spring Water Pump Mechanical Seal Replace Aesseal replace MTU FP/T3S

FAQ

Question 1: Are you a factory or a trading company?
Answer: We are a factory manufacturing mechanical seals. We have regular models in stock and customized products are also available. Please feel free to contact us if you need any.

Question 2: What is the minimum order quantity for each order?
Answer: For products of regular models, the minimum order quantity is at least ten. We welcome you to test the quality of our products and our services through small orders and look forward to long-term cooperation with you next.

Question 3: How can I pay my order?
Answer: We accept T/T, Paypal, D/P, Western Union, Money Gram to pay.

Question 4: Can I try to get a Sample before the order?
Answer: Sure. But our company can not provides you with samples for free, and you also have to pay for the international delivery (freight collect payment).
